1.2358
Classification：
Non-deforming tool steel is a tool steel that can maintain minimal dimensional change during high-temperature heat treatment. Its design goal is to reduce deformation caused by temperature changes and mechanical stress during use.
Tel：
Detailed Introduction
|
Steel Grade (GB) |
Comparison of Grades from Various Countries |
Technical Conditions |
Chemical Composition |
||||||||||||||
|
|
|
|
C |
Cr |
Mo |
V |
S |
P |
Si |
Mn |
Ni |
W |
Al |
Cu |
Nb |
Co |
B |
|
60CrMoV18-5 |
Germany (1.2358)
|
DIN EN ISO 4957-2001 |
0.58 ¦ 0.62 |
4.30 ¦ 4.70 |
0.40 ¦ 0.60 |
0.20 ¦ 0.30 |
≤0.010 |
≤0.030 |
0.20 ¦ 0.50 |
0.70 ¦ 0.90 |
≤0.25 |
|
|
|
|
|
|
1.2358 is a German standard alloy tool steel, which has no corresponding material in China and can be replaced by domestic steel 4Cr5MoSiV1 (H13).
Non-deforming tool steel is a tool steel that can maintain minimal dimensional change during high-temperature heat treatment. Its design goal is to reduce deformation caused by temperature changes and mechanical stress during use. It usually contains a higher proportion of alloying elements such as molybdenum, tungsten, chromium, etc., which help to improve the hardness, wear resistance, and impact resistance of the steel.
The main characteristics of this steel include excellent dimensional stability, strong wear resistance, and good thermal stability. It can still maintain strong hardness and toughness at high temperatures, and is suitable for the manufacture of molds and tools that require extremely high precision. In addition, it has strong impact resistance and can maintain stable performance in high-impact environments, reducing damage caused by impact.
Non-deforming tool steel is widely used in fields that require high precision and high durability, such as cold working molds, hot working molds, cutting tools, and stamping tools. It is widely used in industries such as automobiles, machining, and electronics, and is particularly suitable for the manufacture of high-precision parts and molds, such as precision stamping molds, plastic injection molds, and metal cutting tools. Due to its superiority in processing, non-deforming tool steel can effectively extend the service life of molds and tools and improve production efficiency.
1.2358 (60CrMoV18-5) is a cutting blade suitable for segment tools, stamping tools, scissors, plastic molds, and cutting tools. It can be used for trimming staples, scissors, and blades in multi-part molds, and can also be used for cutting blades in gypsum molds and plastic injection molds.
1.2358 is a German standard alloy tool steel, complying with the standard DIN EN ISO 4957-2001. From the perspective of chemical composition, 1.2358 (60CrMoV18-5) does not have a fully corresponding material in China. 1.2358 is a German heat-resistant mold steel, which does not have a complete corresponding domestic steel grade and can be replaced by domestic steel 4Cr5MoSiV1 (H13).
